Door Hanger Type Shot Blasting Machine
KAILASH INDUSTRIES make Door Hanger Type Shot Blasting Machines has a range of airless shot blasting machine hanger type with number of blast wheels varying according to the job size for the wide variety of work pieces for large production output in terms of surface treatment. The door mounted hook carries the job in & out of the blast cabinet where numbers of blast wheels, depend upon the type of the job for attaining homogeneous finish. Major parts of the machine include blast wheel for giving high production output, door mounted hook for job conveying & the media recovery, consist of bucket elevator, screw conveyor, rotary screen separator etc. & pleated bag reverse jet type dust collector.
Features of Product
Efficient blasting with door-mounted hook system and multiple blast wheels for high production output.
- Door-mounted hook for job conveying
- High production blast wheels
- Complete media recovery system
- Pleated bag reverse jet dust collector
Door Hanger Shot Blasting Machine Specifications
| Model | KI-ASH-60-80, KI-ASH-100-120, KI-ASH-120-150 |
| Job Size | 600mm x 800mm, 1000mm x 1200mm, 600mm x 1200mm |
| Maximum Job Weight | 250 Kg, 500 Kg, 500 Kg |
| Blast Wheel Size | 11½x2½, 12½x2½, 15½x2½ |
| No. Of Blast Wheel | 5 No’s, 2 No’s, 1 No’s |
| Motor | 5 H.P., 16 H.P., 25 H.P., 30 H.P. |
| Dust Collector Motor | 3 H.P., 5 H.P., 7.5 H.P. |
| Capacity | 250 Kg, 500 Kg, 500 Kg |
| Abrasive | 400 Kg, 600 Kg, 800 Kg |
| Blasting Time | 8-10 Minutes |
Customize The Machine As Per Customer Requirement
