Belt Conveyor Type Shot Blasting Machine

Belt Conveyor Type Shot Blasting Machine

Belt Conveyor Type Shot Blasting Machine consists of substantially built blast cabinet with extension vestibules fitted at inlet and outlet ends. Each vestibule station is fitted with sets of rubber sealing curtains to prevent escape of flying abrasive. No. of blast wheel stations is located strategically top of the cabinet fires abrasive on the component. The components are shot blast finishing homogeneously topside. The belt conveyor system is driven by variable speed drives located outside in the enclosures. The belt conveyor is extended both side of the machine for loading and unloading round. The spent abrasive from the blasting operation pass through the perforated floor plates and gravitate down the cabinet hopper into a screw conveyor. The abrasive is then transferred to the boot of bucket elevator. The bucket elevator carries the abrasive vertical and discharges the same into a sieving hopper where dust and fine abrasives are air cleaned ensuring that only clean abrasive is collected in the storage hopper for recirculation purpose. A dust collector unit efficiently exhausts the cabinet to remove dust.

Features of Product

Reliable design with efficient dust collection and smooth abrasive recycling process.

Machine used in:

– Homogeneous shot blast finishing
– Cleaning of casting and forging
– Removal of heat treated scales
– Preparation for protective coatings
– Surface peening of components
– Aesthetic finishing of metal parts
