Cabinet Type Pressure Sand Blasting
KAILASH INDUSTRIES make portable Sand / Shot blasting machine is used for getting a higher production rate in the finishing process...
Customize The Machine As Per Customer Requirement
Cabinet Type Pressure Sand Blasting Machine
KAILASH INDUSTRIES make Pressure blasting machine works on the direct pressure principle of blasting. The pressure blasting machine produces high abrasive velocity which results in completing the job at a faster rate. A pressure vessel, directly bolted below a hopper of a cabinet, has an automatic abrasive refilling arrangement. A fabric bag dust collector is attached with the cabinet for high efficiency of dust collection. A manual shaker is also provided on the dust collector for bag shaking.
The pressure blaster is recommended for fast cleaning, removal of heavy rust and corrosion using coarse abrasives. It is most suitable for etching the surface needed for rubber lining; FRP (Fiberglass Reinforced Plastics) lining and metal spraying, castings and forgings are cleaned speedily. Blast pressure can be controlled from 30 to 90 psig. Almost all types and sized abrasives can be used for blasting, depending on the application.
Model Specifications
| Model | Working Chamber Size (H x W x L) | Overall Dimension (H x W x L) | Max Job Size | Dust Collector | Table Size (Optional) | Air Requirement |
|---|---|---|---|---|---|---|
| KI-PB-9182 | 775 x 910 x 820 mm | 2100 x 950 x 1650 mm | 500 x 500 mm | Bag Filter Type | 300 x 250 mm | 55 CFM @ 80 PSI |
| KI-PB-12090 | 900 x 1200 x 1200 mm | 2300 x 1230 x 2460 mm | 800 x 800 mm | Bag Filter Type | 500 x 350 mm | 70 CFM @ 80 PSI |
| KI-PB-150120 | 1100 x 1510 x 1200 mm | 2600 x 1550 x 2850 mm | 1000 x 1000 mm | Bag Filter Type | 500 x 350 mm | 85 CFM @ 80 PSI |
Optional Features
- Motorized bag-shaking arrangement
- Reverse jet cartridge filter dust collectors
- Higher output blast guns in place of standard
- Foot operated treadle switches for blasting
- ON / OFF fitted with optional accessories
