Aluminum Profile Shot Blasting Machine

Aluminum Profile Shot Blasting Machine

Aluminum Profile Shot Blasting Machine consists of substantially built blast cabinet with extension vestibules fitted at inlet and outlet ends. Each vestibule station is fitted with sets of rubber sealing curtains to prevent escape of flying abrasive. 2 or 4 no’s of blast wheels stations are located strategically all-around of the cabinet fires abrasive on the aluminum profile surface. The aluminum profiles are shot blast finishing homogeneously all-around. The roller conveyor system is driven by variable speed drives located outside in the enclosures. The roller conveyor is extended both side of the machine for loading and unloading round. The spent abrasive from the blasting operation pass through the perforated floor plates and gravitate down the cabinet hopper into a screw conveyor. The abrasive is then transferred to the boot of bucket elevator. The bucket elevator carries the abrasive vertical and discharges the same into a sieving hopper where dust and fine abrasives are air cleaned ensuring that only clean abrasive is collected in the storage hopper for recirculation purpose. A dust collector unit efficiently exhausts the cabinet to remove dust.

Features of Product

Efficient design with full abrasive recovery system and dust collection for consistent blasting performance.

Aluminum Profile Shot Blasting Machine Models

Machine used in:
– Surface finishing of aluminum profiles.
– Homogeneous blasting of aluminum extrusions.
– Cleaning before anodizing or coating.
– Removing surface contamination.
– Pre-treatment before painting.
– Deburring of profile edges.
